    Product overview

    STORK Flood

    Basic Colours
    • Silver   RAL9006
    • Asphalt     DB703

    Other colors available on request

    General Information
    • V220 - 240
    • Hz50 - 60
    • W18 - 280
    • lm2300 - 34660
    • lm/W124 - 142
    • K3000 / 4000 1
    • -40 to +50 (2
    • CRI>70 / >80 3

    Chromaticity tolerance (initial MacAdam): 51-10V; DALI; Midnight dimmingRadio frequency / Power line 4Surge protection: 3; 6; 10 kV (optional) 5Warranty 5 years100 000h (L80B10C10) 6100 000h (L95B10C10) 7

    Body: Die-cast aluminumNeto weight: 12,26 - 14,30 kgMax.wind load area, SCd, m2: 0,047

    Class I

    Class II

    CE

    EAC

    ENEC

    RoHS

    IP66

    IK09

    LED module replaceability

    LED driver replaceability

    1 5000; 5700 K available on request2 240 - 280 W at Ta= -40oC .. +35oC3 Luminaries with color rendering index (CRI): Ra > 90 on request4 Optional. Available only with DALI; 1 - 10 V5 10 kV ( L-N; L/N-PE ) surge protection device available on request6 Average lifetime value for ECO model at Ta = 25C is 100 000h L80/B10*

    *This value is only informative and may change according to selected article. LED Lifetime is strongly depending from LEDs current and junction temperature – increase in LED current and luminaire power lead to increase of junction temperature and as consequence lifetime decrease. Thus, luminaire models with lower power, lower current (and lower junction temperature) will have higher lifetime than standard models and will reach 100 000h L90/B10. And high power and high current luminaire models may have negative lifetime deviation comparing to standard models. To receive precise value please contact VIZULO export representatives.

    7 Standard / High Power / High Density at Ta=25°C, this value is only informative and may change according to selected article

    International approvals

    Finnish Transport Agency Trustr Mark EP Dekra
