WOODPECKER

Product Overview

Architectural lighting is the new, growing lighting specialization. Woodpecker luminaire has been developed for creating a minimalistic and apparent outdoor design. The luminaire can be mounted into various design poles made for specific landscape projects. Also, it can be used together with the Woodpecker pole available in three types and three heights, which delivers a clear and robust design. Woodpecker can be used as territory, parks, pedestrian pathways, and parking lot lighting. A wide range of optics, drivers, connectors allows adapting luminaire to specific project needs.

Basic colours

  • Black RAL9005

Specification

V

220 - 240

Hz

50 - 60

W

15 - 28 | Small
20 - 52 | Large

lm

1845 - 7500 1

lm/W

119 - 155

K

2700 / 3000 / 4000 2

°C

-40 to +50

CRI

>80 / > 90 2

Body: Extruded aluminium

Dimming: DALI / 1 - 10 V / Midnight dimming /

Step dimming / Mains dimming

Lifetime: Eco 100 000 h (L90B10) at Ta = 25 °C* /

Standard / High density 100 000 h (L98B10) at Ta = 25 °C*

Warranty: 5 years

Installation: On flange

Socket: NEMA / Top and Bottom Zhaga

Intelligent control: Stand-alone / Group / CMS

Sensor: Motion / Motion + Daylight / Daylight

Surge protection: 4 / 6 / 10 kV 3

Nature friendly: PC Amber / Red / 1800 K

Corrosion protection: Up to CX

Neto weight: Up to 0.9 kg | Small

Up to 1.6 kg | Large

Class I
Class II
IP65
CE
UKCA
EAC
RoHS
LED module replaceable by a professional
LED driver replaceable by a professional

1 Lumen output indicated at CRI > 70
2 1800 / 2200 / 3500 / 5000 / 5700 / 6500 K available on request along with other not listed CRI and CCT

3 10 kV (L-N; L/N-PE) surge protection device available on request

*This value is only informative and may change according to selected article. LED Lifetime is strongly depending from LEDs current and junction temperature – increase in LED current and luminaire power lead to increase of junction temperature and as consequence lifetime decrease. Thus, luminaire models with lower power, lower current (and lower junction temperature) will have higher lifetime than standard models. And high power and high current luminaire models may have negative lifetime deviation comparing to standard models. To receive precise value please contact VIZULO export representatives.

Technical parameters for final product can differ from typical data by 7% due to special conditions of LED manufacturing processes
