PRELIMINARY!
220 - 240
50 - 60
4 - 10
Jusqu'à 800
Jusqu'à 80
3000 / 4000 1
+10 to +35
>80 / >90 / >95 2
>90 / >95 3
166 x 49 x 75
Body: Aluminium profile
Dimming: DALI / 1-10 V / Pull dimmer / Bluetooth / Non dimmable
Sensor: PIR / PIR + Daylight
Initial chromaticity: MacAdam 3
Lifetime: 50 000 h (L90B10) at Ta = 25 °C*
100 000 h (L80B10) at Ta = 25 °C*
Warranty: 5 years
Optics: PC shade
Mounting: Surface 4
Human Centric Lighting: Available
1 Other CCT available on request
2 Standard LED CRI
3 Sun-Mimic LED CRI
4 Note! The driver is external and must be mounted separately, requiring a minimum 5 mm gap from the ceiling
* This value is only informative and may change according to selected article. LED Lifetime is strongly depending from LEDs current and junction temperature – increase in LED current and luminaire power lead to increase of junction temperature and as consequence lifetime decrease. Thus, luminaire models with lower power, lower current (and lower junction temperature) will have higher lifetime than standard models. And high power and high current luminaire models may have negative lifetime deviation comparing to standard models. To receive precise value please contact VIZULO export representatives.
Technical parameters for final product can differ from typical data by 7% due to special conditions of LED manufacturing processes.
Mounting
Terminal blocks and plugs
