COLIBRI MIDI

Przegląd informacji o produkcie

Solve all your budgeting challenges with the unprecedented value of the Colibri Midi street luminaires. Featuring an IP66 rating, vandal protection, robust aluminium body, brightness up to 13100 lm, and many hardware customization options, Colibri Midi can be the missing link in urban projects of any scale. With the best price-performance ratio on the market. There are two spigot options: post-top and side-entry. You can also choose between the regular and the floodlight models – all versions come with full ENEC/ENEC+/Class I/Class II certification. Further customization includes different drivers, optics, sockets (Zhaga/NEMA), reflectors, and connectors. Colibri Midi – wholesale pricing, luxurious design.

Podstawowe kolory

  • Silver RAL9006
  • Asphalt DB703
  • Black RAL9005
  • RAL7035

Specyfikacja

V

220 - 240 / 110 - 277 1

Hz

50 - 60

W

5 - 87 2

lm

446 - 13100 3

lm/W

90 - 164

K

2700 / 3000 / 4000 4

°C

-40 up to +50 5

CRI

>70 / >80 / >90 4

mm

490 x 190 x 78

Body: Die-cast aluminium

Dimming: DALI / 1-10 V / Midnight dimming / Step dimming / Mains dimming

Initial chromaticity: MacAdam 5

Lifetime: Eco 100 000 h (L90B10) at Ta = 25 °C* /

Standard / High density 100 000 h (L98B10) at Ta = 25 °C*

Warranty: 5 years

Installation: Pre-wired cable 30 cm 6

Spigot: 42 mm / 60 mm / 76 mm 7

Socket: NEMA Top / Zhaga Top and Bottom

Intelligent control: Stand-alone / Group / CMS

Sensor: Motion / Motion + Daylight / Daylight

Surge protection: 4 / 6 / 10 kV 8

Corrosion protection: Up to C5

Neto weight: Up to 4.2 kg

Max. wind load area, SCd: 0.036 m2

Class I
Class II
IP66
IK09
CE
UKCA
RoHS
cUL 9
Zhaga zdi4
ENEC
ENEC Plus 9
DarkSky Approved
International EPD System 10
LED module replaceable by a professional
LED driver replaceable by a professional

1  Maximum operating voltage, ENEC certificate voltage 220 - 240 V, UL certificate voltage 110 - 277 V
2
  Colibri Midi with Zhaga max power 85 W
3  Lumen output indicated at CRI > 70
4  1800 / 2200 / 3500 / 5000 / 5700 / 6500 K available on request along with other not listed CRI and CCT
    Note! Only fixtures with CCT of 3000 K or lower are DarkSky approved!
5  Operating temperature differs depending on chosen output wattage
6  Other lengths available on request
7  Achievable with an adapter for 40 - 60 mm spigot
8  10 kV (L-N; L/N-PE) surge protection device available on request

9  Coming soon
10  EPD registration number: S-P-05886 (link to page)

* This value is only informative and may change according to selected article. LED Lifetime is strongly depending from LEDs current and junction temperature – increase in LED current and luminaire power lead to increase of junction temperature and as consequence lifetime decrease. Thus, luminaire models with lower power, lower current (and lower junction temperature) will have higher lifetime than standard models. And high power and high current luminaire models may have negative lifetime deviation comparing to standard models. To receive precise value please contact VIZULO export representatives.

Technical parameters for final product can differ from typical data by 7% due to special conditions of LED manufacturing processes
