OAK Gen2
Product Overview
Basic colours
Specification
V
220 - 240
Hz
50 - 60
W
15 - 136
lm
Up to 20312 1
Up to 21327 2
lm/W
151 - 174
K
3000 / 4000 3
°C
+10 to +50 | 15 - 75W
+10 to +40 | 76 - 136W
CRI
>80 / >90 / >95 4
>90 / >95 5
Body: Alu-zinc
Dimming: DALI / 1-10 V / Bluetooth / Non dimmable
Sensor: Microwave / PIR / PIR + Daylight
Initial chromaticity: MacAdam 3
Lifetime: 100 000 h (L80B10) at Ta = 25 °C*
50 000 h (L90B10) at Ta = 25 °C*
Warranty: 5 years
2 years (emergency configuration)
Mounting: Wire / Surface / Pendant
Cover: Clear
Human Centric Lighting: Available
6
1 Standard version, lumen output indicated at CRI > 80
2 Premium version, lumen output indicated at CRI > 80
3 1800 / 2200 / 2700 / 3500 / 5000 / 5700 / 6500 K available on request along with other not listed CRI and CCT
4 Standard LED CRI
5 Sun-Mimic LED CRI
6 EPD registration number: S-P-04208 (link to page)
*This value is only informative and may change according to selected article. LED Lifetime is strongly depending from LEDs current and junction temperature – increase in LED current and luminaire power lead to increase of junction temperature and as consequence lifetime decrease. Thus, luminaire models with lower power, lower current (and lower junction temperature) will have higher lifetime than standard models. And high power and high current luminaire models may have negative lifetime deviation comparing to standard models. To receive precise value please contact VIZULO export representatives.
Total lumen output for final product can differ from typical data by 7% due to special conditions of LED manufacturing processes.Lumen output indicated at 4000 K.
Download Documents
Features
Application
Feature glass diffusion hanging plates
Electronics
Light
Terminal blocks and plugs
